VyOS OpenVPN DCO: What Kernel-Speed OpenVPN Means for Your Network

VyOS, the open source network operating system used for routers, firewalls, and VPN gateways, now supports VyOS OpenVPN tunnels with Data Channel Offload. The change arrived in the VyOS Project September 2026 Update, and it mean3s VyOS users can move OpenVPN's encrypted data path out of userspace and into the Linux kernel with a single configuration line.

It's good news for anyone who runs OpenVPN on VyOS, and it's part of a wider trend: DCO is now showing up across router operating systems, consumer hardware, and VPN services. Here's what changed, why it matters, and what to check before you turn it on.

How do you enable OpenVPN DCO on VyOS?

VyOS Rolling now builds OpenVPN 2.7 against the in-tree Linux ovpn kernel module. DCO is off by default, and you enable it per tunnel:

set interfaces openvpn vtun0 offload dco

According to Mandelbit, the team that maintains the upstream ovpn module and contributed the integration, the work landed in three merged pull requests (vyos-build #1281, vyos-1x #5435, and vyos-1x #5441), and existing OpenVPN configurations move to 2.7 and keep working as before. VyOS also checks compatibility when you commit a configuration, so an unsupported cipher or option is reported up front instead of failing once the tunnel is running. VyOS tracks the change in issues T8264 and T9330.

The VyOS team noted that roughly a third of September's work came from the community, and the OpenVPN 2.7 and DCO work was contributed by an upstream OpenVPN developer. That's how open source is supposed to work: the people who build a feature help bring it to the platforms that need it.

What is OpenVPN Data Channel Offload (DCO)?

OpenVPN Data Channel Offload (DCO) is a kernel module that encrypts, decrypts, and forwards OpenVPN tunnel traffic inside the operating system kernel, while the OpenVPN process in userspace keeps handling authentication and key negotiation.

An OpenVPN connection has two parts. The control channel handles the TLS handshake, authentication, and key exchange. The data channel carries your actual traffic, encrypting and decrypting every packet. Traditionally, OpenVPN processed both in userspace, so every packet had to cross from the kernel to the OpenVPN process and back, and encryption ran on a single thread. With DCO, packets no longer make that round trip, and encryption can use multiple CPU cores.

Linux netdev maintainers accepted the ovpn module into the mainline kernel in April 2025, and it shipped with Linux 6.16 in July 2025. OpenVPN 2.7.0, released in February 2026, is the first OpenVPN version built to work with that in-tree module. Because DCO is now part of the kernel itself, Linux-based platforms like VyOS can adopt it without maintaining a separate out-of-tree driver. FreeBSD has its own DCO module, which is how pfSense Plus supports it.

How much faster is OpenVPN with DCO?

The clearest comparison comes from GL.iNet, which ships both OpenVPN with DCO and WireGuard on the same hardware and publishes the throughput for each:

Same vendor, same product line, same testing approach. With DCO, OpenVPN's speed is no longer a reason to choose one protocol over the other, and teams can decide on authentication, identity integration, and access policy instead.

Consumer VPN providers that run OpenVPN at scale report similar gains from their own testing:

• IPVanish added DCO to its Windows app. TechRadar reports download gains of 131% on TCP and 196% on UDP. TechRadar also notes that IPVanish's high-speed DCO mode can't be used together with its Scramble obfuscation feature.
• Norton VPN reports that connection speeds more than doubled and latency fell by 15% in internal testing.
• Windscribe published a speed test showing 801 Mbps down and 701 Mbps up with DCO on Windows.

Our own engineering benchmarks point the same way. In tests by ovpn developer Antonio Quartulli, OpenVPN without DCO reached about 3.61 Gbps, and the same setup with DCO reached about 7.15 Gbps. Our definitive guide to OpenVPN DCO covers those tests in detail.

Your results will depend on your hardware, cipher, and network. DCO helps most when the CPU, not the internet link, is the bottleneck. For a VyOS deployment, that means more throughput from the same hardware and more CPU headroom for routing, firewalling, and other services on the router.

Which VyOS OpenVPN settings work with DCO?

DCO is built for modern, secure configurations, so a few older options don't carry over. Most of them have been discouraged for years. Here's what VyOS and the upstream OpenVPN documentation list for Linux:

On a standard OpenVPN install, an incompatible option makes OpenVPN quietly fall back to the slower userspace path. VyOS reports the conflict when you commit instead, so you know where you stand. DCO is available in VyOS Rolling, and the VyOS OpenVPN documentation notes that enabling it resets the interface, so plan the change for a maintenance window or create new tunnels with DCO enabled.

Which routers and VPN services support OpenVPN DCO?

VyOS is one of several platforms that now ship DCO:

• pfSense Plus. Netgate sponsored the FreeBSD DCO module, and pfSense Plus 22.05 and later support DCO. It isn't available in pfSense CE.
• DD-WRT. DD-WRT includes DCO in builds 53787 and later on kernel 4.4 and newer.
• GL.iNet. GL.iNet routers, including the Mudi 7 and Flint 3, use OpenVPN with DCO and publish the speeds above.
• IPFire. IPFire reported throughput rising from 1 Gbit/s to 10 Gbit/s per tunnel after adding DCO.
• Consumer VPN providers. IPVanish, Norton VPN, and Windscribe have all added DCO to their apps, as covered above.

How does OpenVPN help router makers add DCO?

The OpenVPN Connect Certified program is for router manufacturers and OEMs. Certified equipment is compatible with CloudConnexa and Access Server, uses DCO for high-performance connections, and runs the most recent version of OpenVPN software at the time of certification. We work with manufacturers to get DCO running well on their hardware as part of the process.

GL.iNet's Flint 3 (GL-BE9300) was certified in January 2026. If you build routers and want to add DCO or certify a device, apply through the program page and our team will reach out.

Where else can you use OpenVPN DCO?

If you want the same kernel-level performance without building it yourself, it's already part of our products:

• Access Server. DCO is supported in Access Server 2.12.0 and newer and is on by default in Access Server 3.x. Access Server 3.2.0 and newer use the updated ovpn module aligned with Linux 6.16 and later. Refer to the tutorial to install, verify, and troubleshoot DCO for setup steps, and to the DD-WRT tutorial to connect a DD-WRT router.
• CloudConnexa. You can enable DCO on Linux Connectors and Windows Connectors. Refer to the tutorials for connecting GL.iNet and DD-WRT routers.
• OpenVPN Connect. OpenVPN Connect for Windows supports DCO, but it's off by default. Turn on DCO in OpenVPN Connect so the client side of the tunnel gets the same benefit.

DCO needs to be active on both ends of a tunnel to deliver the full speedup. If one side isn't using DCO, that side stays on the userspace path. A DCO-enabled VyOS router connecting to a DCO-enabled Access Server, for example, keeps the fast path in the kernel from end to end.

The bigger picture

DCO started as an OpenVPN project to make the protocol faster without giving up the security of TLS. Getting the ovpn module into the mainline Linux kernel made it available to every Linux distribution and every Linux-based appliance. Now it's reaching the routers, gateways, and VPN apps that carry business traffic every day.

We're glad to see VyOS bring OpenVPN 2.7 and DCO to its users, and we're grateful to the community contributors who made it happen. If you're running OpenVPN on VyOS, it's worth testing DCO on your next tunnel.

Want kernel-speed OpenVPN with a web-based admin UI, built-in authentication options, and support? Try Access Server, or get started with CloudConnexa.

Frequently asked questions

Does VyOS support OpenVPN DCO?

Yes. As of the September 2026 update, VyOS Rolling ships OpenVPN 2.7 with support for Data Channel Offload through the Linux kernel's ovpn module. It's off by default and enabled per tunnel.

How do I turn off DCO on VyOS?

Remove the offload setting from the tunnel with delete interfaces openvpn vtun0 offload dco and commit. On a standard OpenVPN 2.6 or 2.7 install, add the --disable-dco option to the configuration.

Which ciphers does OpenVPN DCO support?

DCO supports AEAD ciphers only: AES-128-GCM, AES-192-GCM, AES-256-GCM, and ChaCha20-Poly1305. VyOS documents AES-GCM support. CBC ciphers aren't supported.

Do both ends of the tunnel need DCO?

Not to connect. A DCO-enabled peer can connect to peers running OpenVPN 2.4.0 or newer. To get the full speedup, though, both ends should use DCO, because a peer without DCO keeps its side of the tunnel on the slower userspace path.

Which routers support OpenVPN DCO?

VyOS Rolling, pfSense Plus 22.05 and later, DD-WRT builds 53787 and later, IPFire, and GL.iNet routers such as the Mudi 7 and Flint 3 all support DCO. Router makers can add DCO through the OpenVPN Connect Certified program.

What is the OpenVPN Connect Certified program?

It's a certification program for router manufacturers. Certified devices work with CloudConnexa and Access Server, use DCO, and run current OpenVPN software. GL.iNet's Flint 3 was certified in January 2026.

Is DCO available in VyOS LTS releases?

The September 2026 update made DCO available in VyOS Rolling. Check the VyOS release notes for LTS availability.

Does DCO work with TAP or bridged tunnels?

No. DCO supports layer 3 TUN interfaces only. TAP and bridged tunnels keep using the userspace data path.
